Graco Circulation and Return Tube Kits

For recirculation of polyurethane materials from proportioner to 55 gal (200 L) fluid supply drums.

4000 psi (27.6 MPa, 276 bar) maximum fluid working pressure.

Equipment

Part#

Part Description

List Price

Part#246477

Part DescriptionReturn Tube Kit

List Price$517.00

Part#246978

Part DescriptionReactor Circulation Kit for circulation of materials from Proportioner to supply drums. This allows rapid preheating of material by circulating through the Proportioner heaters. Also this prevents wasting material when balancing pressures.

List Price$1,265.00

Parts

Part#

Part Description

List Price

Part#247616

Part NameDesiccant Air Dryer Kit

List Price$310.00

Part#15C381

Part NameReplacement Desiccant Cartridge

List Price$99.25

Part#110110

Part NameSealant, pipe; 6 ml

List Price$39.50

Part#111337

Part NameFitting: Male Run Tee, 3/4 npt (m) run x 3/4 npt (f) branch

List Price$84.00

Part#117453

Part NameFerrule, tube; SST

List Price$13.20

Part#117454

Part NameNut, tube, flareless

List Price$4.90

Part#117532

Part NameElbow, 90 Deg.; 1/2 in. OD tube x 1/2 npt(m)

List Price$37.60

Part#117811

Part NameBushing, strain relief; 3/4 npt (m)

List Price$66.25

Part#162449

Part NameNIPPLE; Pipe Nipple 1/2 (m) x1/4 (m)..

List Price$34.10

Downloads

Name

Download

NameCirculation & Return Tube Kits Instructions - Parts Manual

DownloadDownload
