Graco Air Purge Auto Spray Gun

Automatic Plural Component, Impingement Mix Spray Gun

Maximum Fluid Working Pressure: 3500 psi
Air Inlet Pressure Range: 80-130 psi (0.55-0.9 MPa, 5.5-9.1 bar)
Maximum Fluid Temperature: 200ºF (94ºC)

Equipment

Part#
Part Description
List Price
Part#248376
Part DescriptionFusion Automatic..Spray Gun Round Pattern, AR2929 Mix Chamber
List Price$3,700.00
Part#248377
Part DescriptionFusion Air Purge Automatic Spray Gun
List Price$3,700.00
Part#248378
Part DescriptionGUN - AP,AR5252,AUTO
List Price$3,700.00
Part#248379
Part DescriptionGUN - AP,AR6060,AUTO
List Price$3,700.00
Part#248380
Part DescriptionGUN - AP AF2020 FT0424,AUTO
List Price$3,700.00
Part#248381
Part DescriptionFusion Auto Spray Gun..AF2929
List Price$3,700.00

Parts

Part#
Part Description
List Price
Part#16H881
Part NameBODY,GUN,AUTO FUSION,AP
List Price$1,195.00
Part#100139
Part NamePlug, pipe; 1/8-27 npt
List Price$5.00
Part#100846
Part NameFitting, grease
List Price$5.20
Part#112307
Part NameElbow
List Price$15.40
Part#114070
Part NameSpring Compression
List Price$14.70
Part#116550
Part NameRetaining Ring
List Price$7.30
Part#117490
Part NameSpring, check valve
List Price$3.10
Part#117491
Part NameSpring; Side Seal Cartridge
List Price$4.90
Part#117634
Part NameSwivel, B side; 1/8 npt(m) x #6 JIC(f)
List Price$12.10
Part#117635
Part NameSwivel, A Side; 1/8 npt(m) x #5 JIC(f)
List Price$12.10
Part#117642
Part Name5/16" Spintite Wrench
List Price$25.60
Part#117661
Part NamePin Vice W/Collates
List Price$41.80
Part#117773
Part NameFusion Quik-Shot 3 oz. Grease Cartridge
List Price$8.30
Part#117792
Part Name3oz. Grease Gun
List Price$52.50
Part#118575
Part NameTool Screwdriver, 1/8 blade
List Price$6.30
Part#118665
Part Name4 oz. Tube of High adhesion, water resistant, lithium-based lubricant
List Price$13.10
Part#15B203
Part NamePiston, Fusion Air Purge
List Price$127.00
Part#15B204
Part NameCap, cylinder
List Price$111.00
Part#15B205
Part NamePiston Stop Lock
List Price$17.20
Part#15B206
Part NameLock, safety
List Price$38.30
Part#15B210
Part NameAir Cap, round pattern, for Fusion Air-Purge Gun
List Price$78.75
Part#15B211
Part NameRing, Retaining
List Price$159.50
Part#15B214
Part NameScrew; 5/16-18 x 1/2 in., check valve
List Price$14.00
Part#15B215
Part NameRing Lock
List Price$104.00
Part#15B221
Part NameCoupling Block Bolt; 5/16-24
List Price$19.90
Part#15B223
Part NameValve, cleanoff air
List Price$21.90
Part#15B689
Part NameCover, grease fitting
List Price$19.30
Part#15B801
Part NameAir Cap, Flat Pattern, for Fusion Air-Purge Gun
List Price$47.10
Part#15B993
Part NameSpring, Ring, Lock
List Price$36.10
Part#15D918
Part NameBody; Fusion Auto Air Purge Gun
List Price$1,095.00
Part#172479
Part NameTAG INSTRUCTION
List Price$0.00
Part#197979
Part NameCOVER ES GUN,65/85 KV,AA
List Price$10.30
Part#222385
Part NameCard, warning
List Price$0.00
Part#246012
Part NameFluid Manifold Coupling Block..Includes fluid manifold, shutoff valves and JIC swivels
List Price$404.00
Part#246348
Part NameStainless Steel Side Seal Kit, Includes a packing O-ring for each seal, Qty. 2
List Price$44.10
Part#246349
Part NameA (ISO) Cartridge Assembly complete, Includes A side cartridge, side seal and O-Rings, Stainless Steel
List Price$111.00
Part#246350
Part NameB Side (Poly) Cartridge assembly (complete), Includes complete B side cartridge, side seal and O-Rings, Stainless Steel
List Price$111.00
Part#246352
Part NameB-side (Poly), check valve assembly
List Price$92.00
Part#246354
Part NameO-Ring, clean off air valve; (package of 6)
List Price$69.50
Part#246356
Part NameManifold Fluid Shutoff Valve
List Price$59.75
Part#246357
Part Name40 mesh screens; (0.015 in. 375 micron) (package of 10)
List Price$42.20
Part#246358
Part Name60 mesh screens; (0.010 in. 238 micron) (package of 10)
List Price$42.20
Part#246359
Part Name80 Mesh Screens; (0.007 in. 175 micron) (package of 10)
List Price$42.20
Part#246360
Part NameO-Ring; PTFE, flat tip models only..(package of 3)
List Price$22.20
Part#246361
Part NameFusion Gun Front-end/Spray Head..Includes entire front spray head assembly..less the mix chamber. Order mix chamber
List Price$1,430.00
Part#246491
Part NameFluid Housing Fusion Air Purge Gun
List Price$517.00
Part#246731
Part NameA-side (ISO), check valve assembly,
List Price$92.00
Part#248064
Part NameSafety Stop Assembly; Fusion AP Gun
List Price$224.00
Part#248128
Part NameO-Ring, Side Seal; (package of 6)
List Price$45.70
Part#248129
Part NameO-ring, check valve housing: (Package of 6)
List Price$39.20
Part#248130
Part NameO-Ring, Cartridge Body; (package of 6)
List Price$58.75
Part#248131
Part NameO-Ring; fluid housing; (package of 6)
List Price$44.10
Part#248132
Part NameFluid housing o-ring, pack of 6
List Price$84.25
Part#248133
Part NameO-Ring, check valve face: (package of 6)
List Price$65.75
Part#248134
Part NameO-Ring, piston shaft, (package of 6)
List Price$38.30
Part#248135
Part NamePiston O-Ring; (package of 6)
List Price$93.75
Part#248136
Part NameBack Cylinder Cap, O-Ring; (package of 6)
List Price$93.75
Part#248137
Part NameAir Cap Teflon O-Ring, (package of 6)
List Price$35.40
Part#248279
Part NameCase of 10 - 4 oz. Tubes, High adhesion, water resistant, lithium-based lubricant
List Price$127.00

Downloads

Name
Download
NameAir Purge Automatic Spray Gun Manual
DownloadDownload
