Graco E-10hp Reactor

Grow your business with polyurea projects

If you'd like to add polyurea projects to your lineup, the Graco Reactor E-10hp High Pressure Proportioner is a smart, affordable investment that can help your business grow.

The Graco Reactor E-10hp provides the high pressure power and performance you need to spray polyurea coatings. It's lightweight and portable - and runs on residential power so you don't need to invest in a generator.


Fast start-up times

With the system's innovative boost heat and insulated tanks, material heats up fast so you're up and running sooner. In fact, you're ready to spray in 20 minutes*, compared to over an hour startup time on a standard Graco Reactor E-10.
*With a 240V model.

The boost heat uses the extra available power from the motor circuit when the machine is recirculating and applies that extra power to additional heater rods. Which means that during recirculation mode, you have additional total heater amperage for faster material heating.


Features:

  • Ideal for small to medium projects such as terraces, pools, balconies, tanks, truck bedliners, secondary containment and waterproofing
  • Heats material fast for better productivity
  • Portable, compact and easy to maneuver
  • Easy to use
  • Uses standard residential electrical outlets - no generator needed
  • Affordable investment - compared to a standard Reactor which requires a generator and spray rig

Equipment

Part#
Part Description
List Price
Part#24T100
Part DescriptionReactor E-10HP (E-Series) Portable Proportioner BARE, output 1.0 gpm, 2200 psi max spray pressure, 3 kW heater, (120 volt, 2-cord 20 AMP outlets)
List Price$30,120.00
Part#24T900
Part DescriptionReactor E-10HP (E-Series) Portable Proportioner, BARE, output 1.0 gpm, 2500 psi max spray pressure, 4 kW heater, (230 volt, 2-cord 15 AMP outlets)
List Price$30,120.00
Part#EST100
Part DescriptionReactor E-10HP (E-Series) Portable Proportioner, PKG. output 1.0 gpm, 2200 psi max spray pressure, 3 kW heater, 35' insulated 5 hose bundled with scuff jacket (120 volt, 2-cord 20 AMP outlets)
List Price$31,390.00
Part#EST900
Part DescriptionReactor E-10HP (E-Series) Portable Proportioner, PKG. output 1.0 gpm, 2500 psi max spray pressure, 4 kW heater, 35' insulated 5 hose bundled with scuff jacket (230 volt, 2-cord 15 AMP outlets)
List Price$31,390.00

Parts

Part No.
Part Name
Price
Quantity
Part No.24T974
Part NameKit, O-ring, Tank Lid, E-10HP
Price $116.50
Quantity
Part No.100176
Part NameBUSHING - HEX
Price $55.50
Quantity
Part No.101044
Part NameWASHER - PLAIN,.500
Price $35.60
Quantity
Part No.101078
Part NameY Strainer; (20 Mesh), 3/4" NPT
Price $156.00
Quantity
Part No.101242
Part NameRING - RETAINING,EXT.
Price $7.70
Quantity
Part No.101765
Part NameGROMMET
Price $19.90
Quantity
Part No.102124
Part NameThermometer Dial
Price $327.00
Quantity
Part No.2007096
Part NameFLUID GAUGE, 5000 PSI
Price $108.50
Quantity
Part No.104641
Part NameFITTING - BULKHEAD
Price $80.75
Quantity
Part No.107434
Part NameBEARING THRUST
Price $5.50
Quantity
Part No.108296
Part NameScrew Mach, Hex Washer HD
Price $5.50
Quantity
Part No.111457
Part NameO-ring PTFE
Price $15.60
Quantity
Part No.111600
Part NamePIN GROOVED
Price $5.00
Quantity
Part No.111800
Part NameScrew Cap, Hex HD
Price $4.80
Quantity
Part No.112144
Part NameSCREW - MACH,PAN HD
Price $5.00
Quantity
Part No.113505
Part NameNUT - KEPS,HEX HD,#10
Price $5.40
Quantity
Part No.114331
Part NameSCREW - MACH,PNH,SEMS
Price $5.00
Quantity
Part No.115492
Part NameScrew Machine slot hex
Price $5.00
Quantity
Part No.115711
Part NameTAPE - FOAM 1/2\ WIDE"
Price $10.70
Quantity
Part No.115836
Part NameGuard Finger
Price $5.30
Quantity
Part No.115942
Part NameNut Hex, Flange Head
Price $52.25
Quantity
Part No.116073
Part NameWASHER THRUST,1ST STAGE
Price $5.00
Quantity
Part No.116074
Part NameWasher
Price $5.00
Quantity
Part No.116079
Part NameThrust Bearing
Price $5.00
Quantity
Part No.116171
Part NameBUSHING - STRAIN RELIEF (Replaced 119898)
Price $9.05
Quantity
Part No.116411
Part NameSPRING - COMPRESSION
Price $8.50
Quantity
Part No.116477
Part NameWASHER - FLAT,NYLON
Price $3.00
Quantity
Part No.116478
Part NameWHEEL - PNEUMATIC
Price $72.75
Quantity
Part No.116704
Part NameAdapter STR.; 1/4 x 9/16-18
Price $68.00
Quantity
Part No.2007105
Part NameSensor, Thermocouple
Price $323.00
Quantity
Part No.117493
Part NameScrew, machin, hex washer
Price $5.00
Quantity
Part No.117506
Part NameFitting; Union, inlet, swivel, B side; 1/4 npt(m) x #6 JIC
Price $61.25
Quantity
Part No.117523
Part NameNUT CAP
Price $1.80
Quantity
Part No.117623
Part NameNut Cap
Price $3.80
Quantity
Part No.2007117
Part NameSwitch, cycle counter with cable
Price $91.50
Quantity
Part No.119789
Part NameFITTING - ELBOW,STRT,45 DEG,1/4NPT
Price $7.95
Quantity
Part No.119973
Part NameROPE SST LANYARD 14"
Price $5.50
Quantity
Part No.119975
Part Name1.25" Gray Vinyl Grip
Price $5.10
Quantity
Part No.119992
Part NameFitting; Pipe, Nipple, 3/4 BE
Price $9.65
Quantity
Part No.119999
Part NameSCREW - SHOULDER,SH,#10-24UNC X 1
Price $4.95
Quantity
Part No.120008
Part NamePLUG - TUBE
Price $3.30
Quantity
Part No.120094
Part NameSCREW - PAN HD,PHIL,8-32 UNC X2
Price $1.40
Quantity
Part No.120150
Part NameISOLATOR - PAD,RUBBER
Price $3.95
Quantity
Part No.120336
Part NamePacking O-Ring
Price $13.00
Quantity
Part No.124132
Part NameO-ring
Price $3.10
Quantity
Part No.154636
Part NameWASHER - FLAT
Price $5.15
Quantity
Part No.156971
Part NameFitting; Nipple 1/4
Price $5.00
Quantity
Part No.157350
Part NameFitting; Adapter 3/8" npt x 1/4" npt QNIPPLE, PIPE, HEX
Price $12.20
Quantity
Part No.2007109
Part NameSwitch Over Temp
Price $71.00
Quantity
Part No.15B589
Part NameCOVER - PUMP ROD
Price $5.00
Quantity
Part No.15D757
Part NameHP Visc. Therm. Housing
Price $85.50
Quantity
Part No.15G053
Part NamePLATE - DETENT,DISPLAY
Price $49.40
Quantity
Part No.15G280
Part NameLabel Warning
Price $0.00
Quantity
Part No.15G342
Part NameHose Air, 35 FT. , 1/4" ID
Price $191.50
Quantity
Part No.15H302
Part NameFitting RDCR, 1-3/16 X 1/2
Price $40.60
Quantity
Part No.15H304
Part NameFitting Plug, HLLW Hex. 9/16
Price $13.60
Quantity
Part No.15H306
Part NameAdapter Thermocouple
Price $95.00
Quantity
Part No.160327
Part NameAdapter. displacement pump inlet
Price $120.50
Quantity
Part No.162453
Part NameFitting; Nipple 1/4
Price $24.30
Quantity
Part No.167002
Part NameInsulator Heat
Price $16.70
Quantity
Part No.169970
Part NameNipple; Male Pipe Thread Steel 1/4" (m) NPT
Price $3.10
Quantity
Part No.180131
Part NameBEARING THRUST..weight each
Price $9.40
Quantity
Part No.180199
Part NameReplacement Filter; 20 Mesh Screen, Y-Strainer
Price $55.75
Quantity
Part No.187625
Part NameDrain Valve Handle
Price $8.25
Quantity
Part No.189285
Part NameCaution Label
Price $0.00
Quantity
Part No.195150
Part NameNUT - JAM, PUMP
Price $7.95
Quantity
Part No.196762
Part NamePIN - STRAIGHT
Price $6.70
Quantity
Part No.217374
Part NameLUBRICANT ISO PUMP (1 PINT)
Price $68.50
Quantity
Part No.224807
Part NameBASE VALVE
Price $6.55
Quantity
Part No.239914
Part NameValve, Recirc/spray..Includes: seat and gasket
Price $117.50
Quantity
Part No.244242
Part NameKIT REPAIR,COMB. GEAR ..287057 Superseded by 244242
Price $147.00
Quantity
Part No.247828
Part NameHousing, Heater Module
Price $1,165.00
Quantity
Part No.249855
Part NameRepair Kit displacement pump:..Includes, seals, balls, bearings, intake valve seat
Price $250.50
Quantity
Part No.24K984
Part NameDesiccant Dryer, Mini In-Line
Price $137.50
Quantity
Part No.24K985
Part NameKIT, FAN, COOLING, 120 VAC,E10 ..REPLACES PART 119994
Price $130.50
Quantity
Part No.24K999
Part NameKit, Transducer (Replacing 246123)
Price $326.00
Quantity
Part No.255043
Part NameKIT,HOLDER,FUSE,TER BLK,5X20MM
Price $115.00
Quantity
Part No.287053
Part NameKIT REPAIR,CONN ROD ..
Price $95.75
Quantity
Part No.287055
Part NameKIT REPAIR,DRIVE HSNG ..
Price $180.50
Quantity
Part No.556765
Part NameFitting, #6 JIC 1/4PM
Price $16.80
Quantity
Part No.15E022
Part NameSeat
Price $14.70
Quantity
Part No.24T975
Part NameTank cover w/O-ring for E-10HP
Price $317.00
Quantity
