Graco Reactor 2 H-XP3

Next generation technology for spray foam insulation

What a hydraulic system can do for you:
  • Dependability - robust, durable, longest life spray system
  • Reduce downtime - allows for longer time in between required maintenance
  • Increase daily productivity - capable of extremely high duty cycle

Easy to reach, conveniently-placed electronics

Advanced control technology
  • Tracks, monitors and saves project data
  • Data can be saved and downloaded onto a USB drive
  • Stores up to 24 chemical recipes
  • Drum level indicators

Graco InSite Remote Reporting Technology
  • FREE 6 month trial (Offer Expires December 24, 2015)
  • Transmits real-time job activity you can view on your smart phone, tablet or computer
  • Included on Elite models

Quick and easy troubleshooting thanks to QR code shortcuts
  • Results in less downtime

Sacrificial surge protector
  • Protects your electronics against excessive power spikes

Three-year warranty
  • Covers user display and control modules
  • One of the best in the industry

Equipment

Part#
Part Description
List Price
Part#17H074
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner, BARE, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, (RTD) fluid temperature sensor, 230V, 3ph - 95A
List Price$36,550.00
Part#17H076
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner, BARE, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, (RTD) fluid temperature sensor, 400V, 3ph - 52A
List Price$36,550.00
Part#17H174
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner, BARE, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, (RTD) fluid temperature sensor, Graco InSite, Fluid Inlet Sensors, 230V, 3ph - 95A
List Price$38,470.00
Part#17H176
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner BARE, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, (RTD) fluid temperature sensor, Graco InSite, Fluid Inlet Sensors, 400V, 3ph -52A
List Price$38,470.00
Part#APH074
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, 230V, 3ph - 95A
List Price$42,140.00
Part#AHH074
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) STANDARD Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, 230V, 3ph - 95A
List Price$55,250.00
Part#APH076
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, 400V, 3ph - 52A
List Price$42,140.00
Part#AHH076
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) STANDARD Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, 400V, 3ph - 52A
List Price$55,250.00
Part#APH174
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, Graco InSite, Fluid Inlet Sensors, 230V, 3ph - 95A
List Price$44,270.00
Part#AHH174
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) ELITE Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, Graco InSite, Fluid Inlet Sensors, 230V, 3ph - 95A
List Price$58,610.00
Part#APH176
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, Graco InSite, Fluid Inlet Sensors, 400V, 3ph - 52A
List Price$44,270.00
Part#AHH176
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) ELITE Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Fusion AP gun, Graco InSite, Fluid Inlet Sensors, 400V, 3ph - 52A
List Price$58,610.00
Part#P2H074
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose with blue mesh scuff guard, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, 230V, 3ph - 95A
List Price$42,720.00
Part#PHH074
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) STANDARD Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, 230V, 3ph - 95A
List Price$55,830.00
Part#P2H076
Part DescriptionReactor 2 H-XP3 (H Series) STANDARD Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, 400V, 3ph - 52A
List Price$42,720.00
Part#PHH076
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) STANDARD Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, 400V, 3ph - 52A
List Price$55,830.00
Part#P2H174
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, Graco InSite, Fluid Inlet Sensors, 230V, 3ph - 95A
List Price$44,860.00
Part#PHH174
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) ELITE Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, Graco InSite, Fluid Inlet Sensors, 230V, 3ph - 95A
List Price$59,190.00
Part#P2H176
Part DescriptionReactor 2 H-XP3 (H Series) ELITE Proportioner PKG. output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, Graco InSite, Fluid Inlet Sensors, 400V, 3ph - 52A
List Price$44,860.00
Part#PHH176
Part DescriptionMULTIPLE HOSE PACKAGE Reactor 2 H-XP3 (H Series) ELITE Proportioner, output 2.8 gpm, working pressure 3,500 psi, 20.4 kW heater, # of SIX 50' heated hose w/xtreme wrap, 10' heated whip w/scuff jacket, (RTD) fluid temperature sensor, Probler P2 gun, Graco InSite, Fluid Inlet Sensors, 400V-3ph - 52A
List Price$59,190.00

Parts

Part#
Part Description
List Price
Part#112731
Part NameNUT - HEX,FLANGED
List Price$5.20
Part#117683
Part NameSCREW - MACH, PAN HD
List Price$2.25
Part#247786
Part NameKIT,TRANSFORMER,5400VA,410FT
List Price$2,720.00
Part#247826
Part NameKIT, Reservoir ASSY, Hydr
List Price$1,090.00
Part#247778
Part NameKIT, Housing, Inlet, Reservoir
List Price$228.00
Part#247771
Part NameKIT, Gasket, Inlet
List Price$82.50
Part#247777
Part NameTube, Inlet Reservoir
List Price$136.00
Part#247770
Part NameTubem Return, Reservoir HYD
List Price$109.50
Part#116919
Part NameSCREEN SUCTION, HYDR.
List Price$34.70
Part#255032
Part NameFitting, Plug SAE
List Price$45.60
Part#255021
Part NameFitting, Straight, HYDR
List Price$45.60
Part#117556
Part Namefitting elbow, #8JICX1/2NP
List Price$17.00
Part#113796
Part NameSCREW - FLANGED,HEX HD
List Price$2.00
Part#15H524
Part NameACCUMULATOR - PRESSURE,1/4 NPT
List Price$29.00
Part#119789
Part NameFITTING - ELBOW,STRT,45 DEG,1/4NPT
List Price$6.00
Part#112567
Part NameGAUGE - PRESSURE,FLUID
List Price$104.50
Part#247829
Part NameKit, Cooler, Hydraulic
List Price$329.00
Part#255019
Part NamePump, Hydraulic
List Price$2,380.00
Part#15H512
Part NamePressure Control Label
List Price$9.75
Part#255020
Part NameFitting, Elbow
List Price$89.00
Part#247793
Part NameKit, Hose, Inlet, Coupled
List Price$183.50
Part#15G784
Part NameHose Coupled
List Price$62.50
Part#117464
Part NameClamp Hose
List Price$5.05
Part#247785
Part NameKIT,MOTOR,7.5HP,3PH,230V/480V
List Price$1,650.00
Part#113802
Part NameSCREW - HEX HD,FLANGED
List Price$2.45
Part#15H207
Part NameTensioner Bracket
List Price$43.80
Part#247853
Part NameKit, Adjuster,Belt, Tensioner
List Price$176.50
Part#111802
Part NameSCREW - CAP,HEX HD
List Price$5.75
Part#247856
Part NamePully, Fan
List Price$183.50
Part#803889
Part NameBelt AX46
List Price$20.20
Part#15B456
Part NameGasket Manifold
List Price$24.40
Part#117677
Part NameFitting; Reducer, #6 x #10, JIC
List Price$33.30
Part#117502
Part NameFitting; Reducer, #5 x #8, JIC
List Price$30.60
Part#24U845
Part NamePressure Relief Tube - Stainless Steel
List Price$196.00
Part#295731
Part NameNUT - WIRE,INSULATING (Old Gusmer #0363A)
List Price$5.10
Part#172953
Part NameLABEL DESIGNATION
List Price$3.75
Part#114269
Part NameGROMMET - RUBBER
List Price$4.10
Part#121309
Part NameFITTING,CONN,3/4SAE X 1/2 JIC
List Price$5.20
Part#111218
Part NameCAP - TUBE,SQUARE
List Price$5.55
Part#16U530
Part NameMODULE, system surge protector
List Price$85.75
Part#296607
Part NameClevis Pin Removal Tool
List Price$44.40
Part#24K207
Part NameRTD 2-Component Hose Fluid Temperature Sensor device for Reactor 2 machines. (JIC to JIC fittings)
List Price$459.00
Part#C19843
Part NameSocket Head Screw Cap
List Price$6.90
Part#C20487
Part NameFitting: Nipple, Hex, 3/4" x 3/4"
List Price$18.40
Part#114027
Part NameWASHER - FLAT
List Price$2.45
Part#117284
Part Namegrill Fan Guard
List Price$30.60
Part#296731
Part NameLube Reservoir Hose Assy.
List Price$125.00
Part#206995
Part NameThroat Seal Liquid..1 quart
List Price$36.60
Part#116915
Part NameCAP - BREATHER FILLER
List Price$26.30
Part#247792
Part NameFilter Oil, 18-23 PSI bypass
List Price$48.60
Part#106569
Part NameTAPE - ELECTRICAL
List Price$18.50
Part#15V551
Part Name10 pk of ADM Protective Covers
List Price$14.00
Part#15G782
Part NameHose Coupled
List Price$68.25
Part#116793
Part NameFITTING - ELBOW, HYDR.
List Price$13.30
Part#119865
Part NameSCREW - HH,FLANGED,1/4-20 X .375
List Price$3.65
Part#C19208
Part NameWASHER - LOCK
List Price$6.90
Part#24M174
Part NameKit, Drum Level, Metal
List Price$131.00
Part#124132
Part NameO-ring
List Price$2.20
Part#15H305
Part NameFITTING - PLUG HLLW HEX 1-3/16
List Price$15.50
Part#15H304
Part NameFitting Plug, HLLW Hex. 9/16
List Price$9.75
Part#15H306
Part NameAdapter Thermocouple
List Price$67.75
Part#120336
Part NamePacking O-Ring
List Price$9.25
Part#16A110
Part NameHEAT IMMERSION(2550W,230V)
List Price$362.00
Part#15B137
Part NameSwitch Over Temp
List Price$50.75
Part#15B135
Part NameMixer Immersion Heater
List Price$36.70
Part#123325
Part NameCompression fitting 1/8 NPT, SS
List Price$45.10
Part#117723
Part NameSCREW - MACH,SLOTTED PAN HD
List Price$2.60
Part#255045
Part NameKIT,BLOCK,CLAMP END
List Price$86.50
Part#255022
Part Name3P, 65A Contactor Relay Kit
List Price$228.00
Part#255043
Part NameKIT,HOLDER,FUSE,TER BLK,5X20MM
List Price$82.50
Part#295824
Part NameScrew SHC, 5/16-24 X 3" LG
List Price$7.95
Part#112793
Part NamePacking O-Ring
List Price$3.90
Part#113467
Part NameSCREW - CAP,SOCKET HD
List Price$2.45
Part#120299
Part NameVALVE, DIRECTIONAL, HYDR.
List Price$530.00
Part#C19986
Part NameSCREW - CAP,SH,10-24 X 1.75
List Price$6.90
Part#111800
Part NameScrew Cap, Hex HD
List Price$3.20
Part#M70430
Part NameSCREW - SS,CUP,1/4-28 X .19
List Price$2.05
Part#296653
Part NameKit Pin, Clevis
List Price$99.00
Part#121312
Part NameFitting; Elbow, MA, 3/4 SAE X 1/2 JIC
List Price$9.20
Part#295225
Part NamePLUG PIPE,FLUSH
List Price$5.10
Part#106258
Part NamePacking, O-Ring #032 Viton
List Price$6.40
Part#295229
Part NameFitting, Grease; 1/4-28
List Price$2.90
Part#261863
Part NameKit, Lube Cylinder and Plate
List Price$165.00
Part#295829
Part NameFitting Plug; 3/8 npt (m) X .343
List Price$7.95
Part#295826
Part NameElbow Fitting 90, 1/4 x 3/8..(Old Gusmer 1484-3)
List Price$12.30
Part#295397
Part NameFitting; Elbow 3/8 MPT x1/2
List Price$24.30
Part#295029
Part NamePlate Retainer
List Price$76.75
Part#295030
Part NameCylinder for Hydraulic
List Price$230.50
Part#295031
Part NameBushing Rod
List Price$88.00
Part#296642
Part NamePiston Assembly
List Price$573.00
Part#295640
Part NamePacking O-ring
List Price$2.80
Part#295641
Part NameSeal U-cup
List Price$10.50
Part#295642
Part NameBackup Ring
List Price$6.50
Part#296643
Part NameWear Ring Kit
List Price$80.75
Part#158776
Part NamePacking O-ring
List Price$12.40
Part#295644
Part NameRing Backup
List Price$2.90
Part#295645
Part NameWiper Rod
List Price$6.20
Part#295032
Part NamePump Spacer
List Price$60.00
Part#261502
Part NameSPACER REVERSING SWITCH
List Price$70.25
Part#295034
Part NameHydraulic Cylinder Rod Tie
List Price$39.00
Part#261864
Part NameKit, Clevis
List Price$91.75
Part#177156
Part NamePacking, O-Ring
List Price$5.15
Part#295852
Part NameNut Jam, Baffle
List Price$61.00
Part#296785
Part NameHydraulic Cylinder Repair Kit
List Price$373.00
Part#247824
Part NameValve Drain Cartridge Kit
List Price$293.50
Part#158674
Part NameO-Ring
List Price$10.70
Part#247779
Part NameKit, Seal, seat, valve
List Price$45.10
Part#102814
Part NameFLUID GAUGE, 5000 PSI
List Price$80.50
Part#162453
Part NameFitting; Nipple 1/4
List Price$18.60
Part#247788
Part NameRed, ISO, Left Handle
List Price$30.40
Part#247789
Part NameBlue resin right handle kit
List Price$30.40
Part#112309
Part NameHex Nut Jam
List Price$4.05
Part#100840
Part NameFitting; Elbow 1/4" MxF
List Price$15.30
Part#111457
Part NameO-ring PTFE
List Price$11.70
Part#189285
Part NameCaution Label
List Price$0.00
Part#150829
Part NameCompression Spring
List Price$7.70
Part#117557
Part NameFitting; 45 Male Elbow, 1/2 NPT x 5/8 Tube #10 JIC
List Price$19.20
Part#255149
Part NameDrain Valve Kit, ISO Side
List Price$319.00
Part#255150
Part NameDrain Valve Kit, RESIN Side
List Price$319.00
Part#255148
Part NameKit; Drain Valve, Set, (both handles and grease gun)
List Price$613.00
Part#118459
Part NameFitting; Union Swivel, Straight, 3/4" NPT(f) Swivel x 3/4" NPT (M) For feed hose from transfer pump
List Price$19.80
Part#180199
Part NameReplacement Filter; 20 Mesh Screen, Y-Strainer
List Price$40.10
Part#16V879
Part NameCap, Filter
List Price$60.00
Part#555808
Part NamePlug, 1/4MP W/ Hex HD
List Price$2.90
Part#15D757
Part NameHP Visc. Therm. Housing
List Price$62.00
Part#109077
Part NameBall Valve, 3/4" NPT (FBE)
List Price$126.50
Part#253481
Part NameGUARD - GAUGE,WYE STRAINER,PAINTD
List Price$29.00
Part#24U855
Part NameKIT,MODULE,GCA,MZHP,REACTOR2
List Price$736.00
Part#255047
Part NameKIT,BUSHING,STRAIN RLF,M40 THD
List Price$72.00
Part#255048
Part NameKIT,NUT,STRAIN RLF,M40 THD
List Price$86.50
Part#123967
Part NameOperator Disconnect Knob
List Price$64.50
Part#115942
Part NameNut Hex, Flange Head
List Price$7.10
Part#103181
Part NameWASHER - LOCK EXT (Old Gusmer Part #0655-4)
List Price$4.75
Part#113505
Part NameNUT - KEPS,HEX HD,#10
List Price$3.85
Part#109466
Part NameNUT - LOCK,HEX
List Price$4.50

Downloads

Name
Download
NameREACTOR SPRAY FOAM AND POLYUREA EQUIPMENT BROCHURE
DownloadDownload
NameREACTOR 2 HYDRAULIC PROPORTIONING SYSTEM OPERATION MANUAL
DownloadDownload
NameReactor 2 Hydraulic Proportioning System Repair-Parts Manual
DownloadDownload
NameReactor 2 Hydraulic Startup Quick Guide
DownloadDownload
NameReactor 2 Hydraulic Shutdown Quick Guide
DownloadDownload
NameReactor 2 Hyrdraulic Proportioning Pump Parts Manual
DownloadDownload
NameReactor 2 Air Manifold Kit
DownloadDownload
NameReactor 2 Hydraulic Fluid Inlet Sensor Kit
DownloadDownload
NameReactor 2 Remote Display Module
DownloadDownload
