Graco XP50

Engineered for more flow capacity, the XP50 is great for applications where you want to spray with multiple guns or larger tip sizes. The XP50 provides more porduction, so you can get the job done faster.

Features:
  • Reduced material waste
  • No more throwing away unused mixed material at the end of the day
  • Save money by using less clean-up solvent
  • Consistent material quality - no more guesswork or human error in measuring materials
  • Easy to operate - minimal training required
  • Reduced maintenance costs


Typical Materials:
  • Medium to high solids coatings
  • Hybrid urethane quick-set materials
  • Epoxy primers and topcoats
  • Properly conditioned high solids coatings


XP50 - Quick Set Packages
  • Optimized for quick-setting hybrid and elastomeric urethane coatings
  • Includes a modified mix manifold (typically remote mounted) with fluid pressure gauges and solvent valves for both A and B materials, plus a shorter 10 ft (3.0 m) static mix line to the spray gun. Heated hose is optional
  • Ideal replacement for Graco King Hydra-Cat quick-set packages

Equipment

Part#
Part Description
List Price
Part#282100
Part DescriptionSYSTM,XP,1:1,145/145,BF,PUMP,B
List Price$13,040.00
Part#282101
Part DescriptionSYSTEM, XP50, 1:1, 145/145, cart-mounted sprayer, without hoppers, BF,CNH
List Price$19,030.00
Part#282102
Part DescriptionSYSTEM, XP-50 Quick Set, 1:1, 145/145, cart mounted, with hoppers, quick-set mix manifold, 3/8" x 25' 5600 psi hose (H53825), 1/4" x 10' 5600 psi whip hose (H52510), XTR504 spray gun, and NXT 6500 air motor, BF,CH
List Price$20,440.00
Part#282150
Part DescriptionSYST,XP,1.5:1,145/97,BF,PUMP,B
List Price$13,040.00
Part#282151
Part DescriptionSYSTEM,XP,1.5:1,145/97,BF,CNH
List Price$19,030.00
Part#282152
Part DescriptionSYSTEM,XP,1.5:1,145/97,BF,CH
List Price$20,440.00
Part#282200
Part DescriptionSYSTEM, XP-50, BARE Proportioner, no cart, guns, hoses or manifolds, 2:1 ratio, Xtreme 180 Resin, Xtreme 90 Hardener
List Price$13,040.00
Part#282201
Part DescriptionPlural-Component System, XP-50 Sprayer, 2.0:1 Fixed Mix Ratio, Xtreme 180 Resin Pump / Xtreme 90 Hardener Pump, Cart-Mounted, 25ft 3/8" Dia. hose x 10ft 1/4" Dia. Whip Hose, (3) Static Mixers, 1pkg of 25 mixer elements, and XTR-5 Spray Gun, Without Hoppers
List Price$19,030.00
Part#282202
Part DescriptionSYSTEM,XP,2:1,180/90,BF,CH
List Price$20,440.00
Part#282250
Part DescriptionSYST,XP,2.5:1,180/72,BF,PUMP,B
List Price$13,040.00
Part#282251
Part DescriptionSYSTEM,XP,2.5:1,180/72,BF,CNH
List Price$19,030.00
Part#282252
Part DescriptionSYSTEM,XP,2.5:1,180/72,BF,CH
List Price$20,440.00
Part#282300
Part DescriptionSYSTEM, XP50, 3:1 bare proportioner, 220/72,BF,PUMP,B, no cart, guns, hoses or manifolds
List Price$13,040.00
Part#282301
Part DescriptionSYSTEM,XP,3:1,220/72,BF,CNH
List Price$19,030.00
Part#282302
Part DescriptionSYSTEM, XP-50, 3:1, 220/72, BF, CH, cart-mounted sprayer with hoppers, 3/8" dia. x 25' hose, 1/4" dia. x 10' whip hose, XTR-5 gun
List Price$20,440.00
Part#282400
Part DescriptionSYSTEM,XP,4:1,220/54,BF,PUMP,B
List Price$13,040.00
Part#282401
Part DescriptionSYSTEM,XP,4:1,220/54,BF,CNH
List Price$19,030.00
Part#282402
Part DescriptionSYSTEM,XP,4:1,220/54,BF,CH
List Price$20,440.00
Part#282000
Part DescriptionSYSTEM,XP,5000PSI,NO PUMPS
List Price$13,940.00
Part#283201
Part DescriptionSYSTEM,XP,2:1,180/90,BF,CNH,Q
List Price$19,030.00
Part#283302
Part DescriptionSYSTEM,XP,3:1,220/72,BF,CH,Q
List Price$20,440.00
Part#575107
Part DescriptionComplete System XP-50, 1:1, 145/145, cart mounted with hoppers
List Price$41,310.00

Parts

Part#
Part Description
List Price
Part#262450
Part NameKIT, HEATER MOUNTING, XP, Includes hose and fittings to mount one heater on the XP cart.
List Price$351.00
Part#262393
Part NameKIT, FLUSH, SOLVENT, XP, MERKUR 45:1, Includes air controls, pail siphon, 3 ft. hose to mix manifold
List Price$4,080.00
