Gusmer H-20/35
Designed With Ease of Service in Mind
Gusmer H-20/35 system features easy access and service to the electrical cabinet. With standard off-the-shelf hardware it's an easy-to-use and easy-to-maintain design.
GH-2 Model:
GH-4 Model:
Gusmer H-20/35 system features easy access and service to the electrical cabinet. With standard off-the-shelf hardware it's an easy-to-use and easy-to-maintain design.
GH-2 Model:
- Output: 28 lbs/min
- Max Working Pressure: 2000 psi
- Heater Wattage: 10kW heat
- Max Hose Length: 320'
GH-4 Model:
- Output: 45 lbs/min
- Max Working Pressure: 2000 psi
- Heater Wattage: 15.3kW heat
- Max Hose Length: 410'
Equipment
Part#
Part Description
List Price
Part#26C200
Part DescriptionGusmer H-20/35 GH-2 BARE, output 28 lb/min, max working pressure 2,000 psi, 230V, 10 kW heater, 1ph
List Price$24,430.00
Part#26C201
Part DescriptionGusmer H-20/35 GH-2 BARE, output 28 lb/min, max working pressure 2,000 psi, 230V, 10 kW heater, 3ph
List Price$24,430.00
Part#26C202
Part DescriptionGusmer H-20/35 GH-2 BARE, output 28 lb/min, max working pressure 2,000 psi, 400V, 10 kW heater, 3ph
List Price$24,430.00
Part#26C699
Part DescriptionGusmer H-20/35 GH-4 BARE, output 45 lb/min, max working pressure 2,000 psi, 230V, 15kW heater, 3ph
List Price$34,860.00
Part#26C700
Part DescriptionGusmer H-20/35 GH-4 BARE, output 45 lb/min, max working pressure 2,000 psi, 400V, 15kW heater, 3ph
List Price$34,860.00
Part#APC200
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 1ph)
List Price$29,570.00
Part#APC201
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 3ph)
List Price$29,570.00
Part#APC202
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (400V, 3ph)
List Price$29,570.00
Part#APC699
Part DescriptionGusmer H-20/35 GH-4 Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 3ph)
List Price$40,000.00
Part#APC700
Part DescriptionGusmer H-20/35 GH-4 Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (400V, 3ph)
List Price$40,000.00
Part#CSC200
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (230V, 1ph)
List Price$29,800.00
Part#CSC201
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (230V, 3ph)
List Price$29,800.00
Part#CSC202
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (400V, 3ph)
List Price$29,800.00
Part#P2C200
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 1ph)
List Price$30,210.00
Part#P2C201
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 3ph)
List Price$30,210.00
Part#P2C202
Part DescriptionGusmer H-20/35 GH-2 Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (400V, 3ph)
List Price$30,210.00
Part#P2C699
Part DescriptionGusmer H-20/35 GH-4 Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 3ph)
List Price$40,640.00
Part#P2C700
Part DescriptionGusmer H-20/35 GH-4 Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (400V, 3ph)
List Price$40,640.00
Part#AHC200
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 1ph)
List Price$37,680.00
Part#AHC201
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 3ph)
List Price$37,680.00
Part#AHC202
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (400V, 3ph)
List Price$37,680.00
Part#AHC699
Part DescriptionGusmer H-20/35 GH-4 Multiple Hose Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (230V, 3ph)
List Price$50,140.00
Part#AHC700
Part DescriptionGusmer H-20/35 GH-4 Multiple Hose Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion AP Gun (400V, 3ph)
List Price$50,140.00
Part#CHC200
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (230V, 1ph)
List Price$37,910.00
Part#CHC201
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (230V, 3ph)
List Price$37,910.00
Part#CHC202
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Fusion CS Gun (400V, 3ph)
List Price$37,910.00
Part#PHC200
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 1ph)
List Price$38,320.00
Part#PHC201
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 3ph)
List Price$38,320.00
Part#PHC202
Part DescriptionGusmer H-20/35 GH-2 Multiple Hose Package, output 28 lb/min, 10kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (400V, 3ph)
List Price$38,320.00
Part#PHC699
Part DescriptionGusmer H-20/35 GH-4 Multiple Hose Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (230V, 3ph)
List Price$50,780.00
Part#PHC700
Part DescriptionGusmer H-20/35 GH-4 Multiple Hose Package, output 45 lb/min, 15kW heater, max working pressure 2,000 psi, FIVE 50' heated hose bundle w/scuff jacket, 10' heated whip hose w/scuff jacket, (FTS) fluid temperature sensor and Probler P2 Gun (400V, 3ph)
List Price$50,780.00
