Solvent Flush Kits

For use with Fusion Spray Guns

Models 248139 and 256510
  • 1 quart (90.95 liter) solvent cup


Model 248229

  • 5 gallon (19 liter) pail with Husky 307 Diaphragm Pump
  • 100 psi (0.7 MPa, 7.0 Bar) maximum fluid working pressure


Equipment

Part#
Part Description
List Price
Part#248139
Part DescriptionKit, Solvent Flush Fusion AP & MP Gun, 1 qt.
List Price$620.00
Part#248229
Part DescriptionFusion Gun Flush System, 5 gal, Pail Kit, Fusion AP & MP Guns
List Price$1,530.00
Part#256510
Part DescriptionKit, Solvent Flush, Fusion CS Gun
List Price$677.00

Parts

Part#
Part Description
List Price
Part#100021
Part NameSCREW - CAP HEX HD
List Price$4.05
Part#100030
Part Name1/4M x 1/8F Bushing
List Price$20.30
Part#101108
Part NamePAIL - METAL
List Price$103.00
Part#104984
Part NameFitting; Tee Female 1/4
List Price$21.60
Part#108047
Part NameSPRAYER SOLVENT FLUSH
List Price$332.00
Part#108056
Part NameFITTING - LINE,AIR
List Price$37.40
Part#113093
Part NameCONNECTOR - PIPE
List Price$8.30
Part#114371
Part NameKNOB - SCREW
List Price$17.70
Part#116315
Part NameFITTING - COMPRESSION,ELBOW
List Price$9.45
Part#116316
Part NameFitting Compression, STR.
List Price$7.90
Part#117510
Part NameCoupler, air line, 1/4 NPT Male Quick Disconnect
List Price$47.30
Part#150136
Part NameVALVE - SERVICE AIR
List Price$11.80
Part#151519
Part NameFitting; Nipple, reducing; 1/4 npt x 1/8 npt
List Price$15.30
Part#15B221
Part NameCoupling Block Bolt; 5/16-24
List Price$24.30
Part#15D435
Part NameManifold Flush, Fusion
List Price$122.50
Part#15R906
Part NameMANIFOLD,FLUSH,FUSION, CS
List Price$91.50
Part#15R906
Part NameMANIFOLD,FLUSH,FUSION, CS
List Price$91.50
Part#162449
Part NameNIPPLE; Pipe Nipple 1/2 (m) x1/4 (m)..
List Price$29.50
Part#169970
Part NameNipple; Male Pipe Thread Steel 1/4" (m) NPT
List Price$2.15
Part#180664
Part NameAdapter
List Price$76.25
Part#180716
Part NameLABEL WARNING
List Price$0.00
Part#190126
Part NameBODY - BLEEDER
List Price$117.00
Part#191872
Part Name1/8" x 1/4" Gun Block to Hose Fitting
List Price$7.50
Part#197971
Part NameHOSE - POLYETHYLENE,STRAIGHTENED
List Price$5.65
Part#206264
Part NameValve: Air Needle
List Price$33.60
Part#218798
Part NameStrainer
List Price$10.70
Part#240212
Part NameCOVER - REPLACEMENT
List Price$577.00
Part#243803
Part NameHose Coupled
List Price$49.60
Part#243804
Part NameHOSE COUPLED
List Price$58.75
Part#244524
Part NameWire Ground Assy W/Clamp
List Price$62.75
Part#246356
Part NameManifold Fluid Shutoff Valve
List Price$73.00
Part#246356
Part NameManifold Fluid Shutoff Valve
List Price$73.00
Part#D31211
Part NamePUMP DIAPHRAGM 307
List Price$777.00

Downloads

Name
Download
NameSolvent Flush Kits Manual
DownloadDownload
