Spray Booth Filters

Series 225T Polyester Intake Panels
Two-ply 1" nominal media construction, using 3/4" nominal white polyester on the upstream, with internal tackification followed by a 1/4" dense white polyester downstream constructed with 9 gauge galvanized wire support.

Series 325T Polyester Intake Panels
Three-ply nominal media construction, using 1 1/2" nominal white/green dual density, multidenier polyester upstream, with internal tackification followed by a 1/4" dense white polyester downstream constructed with 9 gauge galvanized wire support.

SAR-1 Intake Panel
Blend of polyester fibers coated with an ecologically sound tackifier and scrim layer on the downstream side for added strength and rigidity. This product has a wet tack. A chlorinated paraffin add-on which has a sticky feel and helps hold dust particles on the media, made without the use of PVC or other unfavorable chemicals, constructed with 9 gauge galvanized wire support.

Polyester Bulk Media Rolls/Square Exhaust Filters
Polyester Synthetic Fiber (PSF) media is extremely resilient and will withstand direct moisture. In many cases, a PSF media is the ideal alternative to spun glass. It makes an excellent prefilter for high efficiency filters and offers a high resistance and dust holding capacity.

Equipment

Part#
Part Description
List Price
Part#20202M
Part Description20x20x2 Polyester Media Squares (priced each)
List Price$2.73
Part#20x20grid
Part Description20x20 Maxi Grid 3 Ply Panel With Wire Frame and Sticky Tacky on One Side. (priced each)
List Price$6.83
Part#20x20grid-1ply
Part Description20x20 Maxi Grid 1 Ply Panel With Wire Frame and Sticky Tacky on One Side. (priced each)
List Price$4.58
Part#40x90 media
Part Description40 x 90 x 1 Polyester Media roll (priced each)
List Price$117.91
Part#48x90 media
Part Description48 x 90 x 1 Polyester Media Roll (priced each)
List Price$141.66
Part#20201M
Part Description20x20x1 Polyester Media Squares (priced each)
List Price$2.50
Part#25RT2020
Part Description20 x 20 2 ply filter (box of 24)
List Price$183.60
Part#4101100
Part Description20 x 20 3 PLY PANEL (priced each)
List Price$8.58
Part#HF314
Part Description48" x 60' Poyester Media Roll, Heavy Resin (priced each)
List Price$113.33
Part#HF400
Part Description48" x 90' Polyester Media Roll, Soft Thermal (priced each)
List Price$111.66
