IPM IP-02 Transfer Pump
IPM's 100 Series 2:1 is designed specifically for difficult to handle materials. The immersed lower pump, tie-tubes, and sealing bung bushing allow quick drum change without exposing the system to contamination and moisture.
New design innovations to simplify handling and application of polyurethane, polyurea, and other two component materials.
New design for cleanable tubes
IP and OP Series Pumps now have high viscosity "B" resin capabilities
Features
New Designs for:
- Higher Viscosities
- Ease of cleaning
- Fluids with 245a agent
- Low Ceiling Installations
- Interchangeable pump lengths
New design innovations to simplify handling and application of polyurethane, polyurea, and other two component materials.
New design for cleanable tubes
- Allows thorough cleaning of the pump fluid tubes
- Both the IP-02 and OP series have easily cleanable fluid tubes
- Feature allows for nearly an unlimited number of pump rebuilds
IP and OP Series Pumps now have high viscosity "B" resin capabilities
- "B" resins with the newer 245fa blowing agent can have viscosities up to 2000cPs
- OP and IP series pumps have increased suction capability by 69%
- Pumps have the capability of pumping the new "B" resins without heat or pressurization
- The new design nearly eliminates foaming of material
- Outlet ports are now a standard 3/4" NPT
Features
- Fully air operated
- 2 ball piston design provides uniform positive displacement
- Extremely durable pump with long life packing
- Specially designed piston seals do not come into contact with material pumped. Hence, very long life as it can handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.
Equipment
Part#
Part Description
List Price
Part#810203
Part DescriptionIP-02SST Drum Length 2:1 Transfer Pump, Stainless Steel
List Price$1,310.00
